Collections
Ready-written specifications named after London areas, so one choice settles frame, glass, colour and hardware.
- Collections
- 8
- Quote
- 3 working days
- Lead time
- 6–8 wks
- Swap any element up to survey
- PAS 24 on every external collection
- Uw 1.0 to 1.3 W/m²K, by collection
The whole collections square on and filling the frame, in the chiswick, casement and sash configuration, shot level in flat overcast light against a plain wall so the proportion and the frame-to-glass ratio can be read without perspective. Unit at 48 mm sightline, to 1400 x 2400 mm, Uw 1.2.
3:4
Close detail of the meeting line at eye level in raking light, tight enough that the joint and the seal are legible and the to 2500 x 4000 mm, Uw 1.0, minimum 5 degree fall sightline can be measured off the frame, with the background thrown out of focus.
1:1
The hand-level detail: collection-matched handle set photographed in use on the collection default ral finish, close enough to show the surface texture and the fixing, with a hand on the handle for scale.
4:3
From inside the room looking out through the collections, the unit open where it opens, late afternoon light on the floor, so the product is seen the way it is lived with rather than the way it is sold.
16:9
The collections at dusk from outside, closed, the room lit behind the glass, so the finish and the glass line read against the light.
3:4
Specifications & options
Collections
Description
A collection fixes four decisions at once: frame, glass make-up, colour and hardware. Each is named after the London area whose housing stock it suits. Chiswick is casement and sash at a 48 mm sightline for Victorian terraces. Hampstead is slim-sliding at a 20 mm interlock, leaf to 3000 x 3200 mm, for rear extensions. Marylebone is steel-framed internal screens at 25 mm. Any element can be substituted up to survey, and most people substitute one. The specification is already written, so the quote is a price rather than a design exercise.
Specify it when
Use when the house type is conventional and you would rather make one specification decision than five.
Specification
- Collections available
- 8, London-named
- Decisions fixed per collection
- 4: frame, glass, colour, hardware
- Chiswick, casement and sash
- 48 mm sightline, to 1400 x 2400 mm, Uw 1.2
- Hampstead, slim-sliding
- 20 mm interlock, leaf to 3000 x 3200 mm, Uw 1.1
- Ealing, bi-folding
- 52 mm sightline, leaf 1200 x 2700 mm, Uw 1.3
- Marylebone, steel internal
- 25 mm sightline, leaf to 1100 x 2600 mm
- Richmond, frameless rooflight
- to 2500 x 4000 mm, Uw 1.0, minimum 5 degree fall
- Substitutions
- Any element, up to survey
- Quote turnaround
- 3 working days
- Lead time
- 6-8 weeks survey to install; quote in 3 working days
Configurations
- Chiswick, casement and sash
- Hampstead, slim-sliding
- Ealing, bi-folding
- Marylebone, steel internal screens
- Richmond, rooflights and lanterns
- Shoreditch, steel external doors
- Kensington, entrance doors
- Barnes, timber bay and oriel
Glass
- Double 4/20/4 as standard in every collection
- Triple upgrade across the collection
- Acoustic laminate on the street elevation only
Finishes
- Collection default RAL
- Any of 213 RAL
- Anodised bronze or black
- Dual colour
Hardware
- Collection-matched handle set
- TS 007 3-star cylinder
- Concealed hinge
- Flush pull on steel screens
Performance
- Thermal
- Uw 1.0 to 1.3 W/m2K depending on collection
- Acoustic
- 32 dB Rw as standard; 44 dB Rw with the triple upgrade
- Security
- PAS 24 on every external collection; Secured by Design
- Weather
- BS 6375 weathertightness; BS 5516-2 on the Richmond rooflights
